VLX 100 Arched / Custom Door

VLX 100 Arched / Custom Door in Davie, FL | Sightline Windows & Doors Davie

The VLX 100 Arched / Custom Door is a CNC-bent aluminum arched entryway built for homeowners in Davie who want their front door to do more than open and close. It’s a curved architectural statement with structural precision, engineered by ViewLux and installed by our team at Sightline Windows & Doors Davie. We’ve been the authorized installation partner for ViewLux products in Davie, FL since 2012, and this door represents exactly why that partnership matters: factory-level engineering meets local expertise that understands Davie’s wind-load requirements, afternoon sun exposure, and the architectural mix of Spanish-inspired estates and modern new builds throughout neighborhoods like Long Lake Ranches and Ivanhoe. If you’re replacing a standard rectangular entry with something that actually frames your home’s character, call us at (754) 254-8492 to schedule your free on-site measurement.

Call (754) 254-8492

Product Overview - VLX 100 Arched / Custom Door

The VLX 100 Arched / Custom Door starts with a single aluminum extrusion that’s CNC-bent to your exact radius, not pieced together from short segments that telegraph seams and compromise structural integrity. That bent profile, 2.56 inches wide with a 0.098-inch wall thickness, carries load across the full arc without the flex or fatigue you’d see in thinner stock. Maximum span is custom fabricated to order, which means we’re not forcing your opening to fit a factory limit. We measure, the ViewLux factory bends, and we install.

Buyers in Davie choose this series for three reasons. First, the arched silhouette reads as permanent architecture, not an afterthought. It suits the Mediterranean and Spanish Colonial homes common in Davie’s older neighborhoods, but we’ve also installed VLX 100 units on contemporary builds in Shenandoah and Cooper’s Colony where the curve softens an otherwise rigid facade. Second, aluminum doesn’t swell, rot, or invite termites, which matters in South Florida’s humidity cycles. Third, the thermal break construction means you’re not accepting a penalty on your energy bill for choosing a metal door.

Every VLX 100 we install in Davie arrives with the glass, finish, and hardware pre-configured to your spec. There’s no field modification of the arch. That precision is why ViewLux restricts installation to authorized partners who’ve demonstrated proper handling of these custom-fabricated units.

Technical Specifications

Before

After

Performance Features

Thermal Efficiency

The VLX 100 uses a full thermal break that separates interior and exterior aluminum surfaces, cutting conductive heat transfer. NFRC-rated performance means the numbers are verified, not claimed. In Davie, where summer attic temperatures can push adjacent framing past 140°F, that break keeps the interior frame surface closer to room temperature and reduces the load on your AC.

Acoustic Performance

Multi-point compression seals and the mass of the 0.098-inch wall thickness combine to dampen exterior noise. We’ve had homeowners in Davie near I-75 and Griffin Road specifically request the VLX 100 with laminated glass for the additional STC improvement. The door won’t make your foyer silent, but it will drop the perceived volume of traffic and aircraft noticeably.

Airtightness & Weather Seal

Compression seals at the jamb, head, and sill are sized to the frame extrusion, not generic bulb gasket pressed into a slot. The AAMA 812 low-expansion foam sealant at perimeter joints fills irregularities in the rough opening without distorting the frame. That matters because air leakage is where most “energy efficient” doors actually fail.

Waterproofing

The sill profile includes a dam and weep system that handles wind-driven rain at the angles Davie sees during summer storms. Water that breaches the primary seal is captured and drained to the exterior. We verify this with a calibrated spray test after every installation.

Wind Resistance

The VLX 100 is wind-load rated for local climate requirements, including the pressures specified in Broward County’s HVHZ provisions. The custom-fabricated arch doesn’t create weak points where wind can concentrate stress. For Davie homes in flood zones or exposed lots, the laminated glass option adds missile-impact resistance.

Security & Hardware

Multi-point locking engages at the sill and head as well as the latch side. The 2.56-inch profile width accommodates robust strike plates without thinning the wall section. We pair the VLX 100 with hardware rated for the door’s weight and frequency of use, not a generic handle set that will sag in two years.

Color & Glass Options

The six finish options on the VLX 100 cover the architectural range we see across Davie. Premium Black and Anodized Silver read as contemporary, suited to the clean-line homes in newer developments. Bronze and Champagne bridge traditional and transitional, working well with the stone and stucco palettes common in Long Lake Ranches and Forest Ridge. Pure White stays crisp on coastal-inspired exteriors. Teak Wood grain finish gives the warmth of wood without the maintenance liability, which is why we recommend it for homes in Davie’s canopy-heavy neighborhoods where sun and moisture cycle hard on natural materials.

Glass selection depends on what the door needs to do. Clear glass maximizes daylight and visibility, appropriate for covered entries or secondary doors. Frosted and Obscure provide privacy for bathrooms, pool baths, or front doors that open directly into living space. Low-E coating is standard recommendation for Davie because it reflects infrared heat without darkening the view. Tempered glass meets safety code for doors and sidelites. Laminated glass adds the impact resistance required in Broward County’s High Velocity Hurricane Zone and provides acoustic damping as a secondary benefit. We’ll walk you through the tradeoffs during your free estimate.

Installation by Sightline Windows & Doors Davie in Davie

We install the VLX 100 Arched / Custom Door to AAMA 2400/2410 standards because that’s what ViewLux requires for warranty coverage, and because we’ve seen what happens when arched units are set by crews who treat them like standard rectangles. The arch doesn’t forgive shimming shortcuts or out-of-square rough openings.

Our process starts with a pre-install inspection of the rough opening in your Davie home. We check width, height, radius match, and squareness. If the masonry or framing needs correction, we address it before the door arrives. The VLX 100 is custom fabricated; there’s no running to the warehouse for a different size.

Setting the frame means level, plumb, and square to 1/8 inch across the full span. The CNC-bent arch is rigid, so the opening has to meet it, not the other way around. We secure with appropriate fasteners for the substrate, whether that’s block, poured concrete, or wood framing with structural sheathing.

Perimeter sealing uses AAMA 812 low-expansion foam sealant at all joints between frame and rough opening. This isn’t generic gap filler. It’s specified to expand without distorting the frame and to maintain adhesion through the thermal cycling that Davie’s climate delivers. We cap with compatible sealant at the interior and exterior faces.

Final steps include hardware adjustment, sweep contact verification, and a water spray test that simulates wind-driven rain. We clean the work area and walk you through the operation and maintenance before we leave.

Improper installation voids the manufacturer warranty. That’s not a scare tactic; it’s the condition ViewLux places on coverage. An authorized installation partner like Sightline Windows & Doors Davie exists specifically to prevent that void. In Davie, where the Building Department enforces HVHZ standards and inspectors know what proper door installation looks like, doing it right the first time also means passing inspection without callbacks.

Frequently Asked Questions - VLX 100 Arched / Custom Door

What is the lead time for the VLX 100 Arched / Custom Door?

Lead time typically runs 6 to 8 weeks from final measurement and deposit, because each unit is CNC-bent to your specific radius and span at the ViewLux factory. We’ll confirm current production scheduling when you call (754) 254-8492 for your estimate.

Does the VLX 100 qualify for energy tax credits?

The NFRC-rated thermal break construction and Low-E glass options may contribute to qualifying your project under federal energy efficiency credits, though eligibility depends on the full assembly meeting current program thresholds. We provide the performance documentation your tax preparer needs. Call (754) 254-8492 and we’ll discuss how to spec for maximum credit potential.

What warranty comes with the Arched / Custom Door?

ViewLux provides a limited lifetime warranty on the aluminum frame and finish, with glass and hardware covered under separate terms. Coverage requires installation by an authorized partner like Sightline Windows & Doors Davie following AAMA standards. We’ll provide the full warranty document before you commit.

Can I customize the size?

Yes. The VLX 100 is custom fabricated to order with no standard maximum span. We measure your existing opening or design intent, and the factory bends the arch to that exact specification. Call (754) 254-8492 to schedule the measurement that starts the custom process.

How do I maintain aluminum frames in Davie’s climate?

Rinse the frame with fresh water every 3 to 4 months to remove salt and dust accumulation, then wash with mild soap and a soft cloth. Avoid abrasive cleaners or solvents that can degrade the finish. Lubricate hinges and lock mechanisms annually with a silicone-based product. The thermal break and sealed glass unit require no homeowner maintenance.

Get a Quote - VLX 100 Arched / Custom Door in Davie

Ready to replace a standard entry with something that actually belongs to your home’s architecture? Call Sightline Windows & Doors Davie at (754) 254-8492 to schedule your free on-site measurement. We’ll assess your opening, confirm radius and span feasibility, review glass and finish options, and provide a written line-item quote with no obligation. Every VLX 100 Arched / Custom Door we install in Davie carries the backing of our authorized ViewLux partnership and our own workmanship commitment.

Written by the team at Sightline Windows & Doors Davie, serving Davie, FL since 2012.
